Specifications
- Primary (Input) Volts: 0-12V
- Maximum Output Amperage: 300 AMPs (DC Output Only)
- Rated Output and Duty Cycle: 220 AMP @ 60% Duty Cycle
- Dimensions: 18" (462 mm) x 9.3" (236 mm) x 2.7' (70 mm)
- Weight: 8 lbs. (3.63 kg)
- Wire Diameters: 0.030" (0.8 mm) to 0.047" (1.2 mm)
- Wire Feed Speed: 1,000 Inches per Minute (Max IPM)
- Cable Length: 25ft (7 meters)
- Consumables: 14H Series TWECO style
- Ergonomic Design: This innovative design reduces wrist fatigue by under slinging the pool of wire. This ultimately allows you to weld for longer periods of time and creates an optimal combination of balance and usability
- Integrated Spool Life Indicator: Built-in indicator arrow shows when wire is running low, reducing the risk of interrupting your project
- Excellent Control: The wire feed speed control knob is placed at your fingertips; this allows you to precisely control the wire feed speed while welding so you can easily dial in the perfect settings
- Out of Position Welding: The 360-degree gooseneck allows you to adjust the angle of the torch neck. This feature makes this spool gun optimal for out of position welding
- Mounted Hook for Safe Storage: Integrated hook allows user to safely store spool gun when not in use
- Warranty: 30 days
