Hinged Duct Access Door - 16 x 16

Door for Duct Access with no hinge has an insulated door panel, along with the gasketing between the door and frame assures a tight seal without obstruction in the air system. Unit comes with extra - self tightening, hand operated cam latch(es) making the door panel completely removable. Galvanized steel material with mill finish. 2 Latches. Silver Finish. 10"W x 10"H Outside Flange Dimensions. 8-3/4"W x 8-3/4"D x 5/8"H Return Flange Dimensions.

Universal flush access door (stainless steel) for walls & ceilings. Designed for installation in all types of flush surfaces. This unit is good for exterior applications or areas where corrosion or moisture is a concern. 2 Latches. Stainless Steel Finish. 17-5/8"W x 17-5/8"H Outside Flange Dimensions. 16-1/4"W x 1-1/4"D x 16-1/4"H Return Flange Dimensions.

Walk Through Access Door for access to duct work & air handling units. Aluminum Frame w/ Galvanized Steel Door Panel. " L "Handles ship loose with the unit. 1-15/16" (w) x 1-1/2" deep extruded aluminum frame w/ mitred corners. 2 Latches. Mill Finish. 32-1/2"W x 38-1/2"H Outside Flange Dimensions. 30 W x 1-5/8"D x 36 H Return Flange Dimensions.

Designed specifically for installation in drywall walls & ceilings after the drywall has been installed. The door flange is perforated as taping bead, with pre-punched holes. The door panel is formed with flanges on four sides, to operate freely with no binding, sagging, or distortion. 2 Latches. White Finish. 26-4/7"W x 26-4/7"H Outside Flange Dimensions. 24-1/8"W x 24-1/8"D x 1-7/8"H Return Flange Dimensions.

Surface Mounted Access Door - 24" x 24" This 24"W x 24"H access door is made of solid 16 gauge steel for long lasting duability and dependability. 25-1/4"W x 25-1/4"H frame. Rounded safety corners on door provides an architecturally pleasing appearance. Exposed continuous piano hinge allows the door panel to open to 175 degrees. Mounting holes in each corner of the frame allow for easy installation. Since there is no frame to extend into the wall or ceiling, it is ideal for access to odd size opening. White finish. 4 latches.
