Zurn HXT-60 6 Gallon Expansion Tank, Hydronic, 1/2 In. MNPT

Zurn 112-950XLT2 1-1/2 In. FNPT x FNPT Double Check Valve Assembly - 175 PSI - Lead-Free Cast Bronze Designed for installation on potable water lines to protect against both backsiphonage and backpressure of polluted water into the potable water supply. A test cock plug is provided to protectagainst fouling caused by insects, dirt and debris. Assembly shall provide protection where a potential non-health hazard exists. Standards Compliance Unless otherwise noted, applies to 3/4" thru 2" Horizontal ASSE® Listed 1015 (Vertical flow-up:1 1/4" thru 2") IAPMO® Listed CSA® Certified (Vertical ...

Watts 1-1/2" Steam Trap 0037107 This float and thermostatic steam trap, 1 1/2" with .500 orifice, is used in steam main drips and process applications to provide continuous air venting and condensate removal. It features an iron body H-pattern design, stainless steel valve head, seat, float and thermostatic air vent. It is water hammer resistant and can be serviced without disturbing system piping and it is ideal for use in unit heaters, heat exchangers/reboilers, air heating coils, steam main drips, and process equipment. Operating pressure is 15 PSI.

Thermal expansion occurs as domestic water is heated. Left unchecked, the resulting pressure increase can cause relief valve discharge and other potentially hazardous conditions. Therm-X-Trol® expansion tanks absorb this expanded water, keeping water pressure at a safe level. Features: Antimicrobial liner neutralizes bacteria on contact Patent pending Turbulator™ water diffuser 50 psi precharge - the industry's highest Deep drawn steel domes for 2X the strength of other tanks Thickest diaphragm for extra long life Hoop and groove design for added reliability Stainless steel system ...

This non-potable water expansion tank is designed for use in commercial and residential closed loop hydronic heating system piping to control the thermal expansion of hot water and maintain system pressure below the relief setting of the relief valve. This carbon steel tank is pre-charged at 12 PSI, tank volume is 6.0 gallons and features a durable expansion membrane that prevents contact of the water with the air in the tank. This rugged butyl diaphragm minimizes loss of the air change and ensures long and trouble-free life for the system. This tank is made of carbon steel with epoxy ...

The Series HFT tank is designed to absorb the force of thermal expansion of heating water and to maintain proper pressurization in a closed hydronic system. The heavy duty butyl diaphragm separates system water from the air in the tank preventing water logging problems. Features: Residential and light commercial applications Helps prevent excessive pressures in heating systems Increases system performance Reduces oxygen corrosion Prevents waterlogging In-line and floor mount installation Max. operating temp 240°F Max. working pressure of 100 psi
