Vestil™ Reel Rack Starter Unit, 51-7/8"W x 36-1/2"D x 118-1/2"H

With the carton Flow Rack, cartons are gravity fed on rollers for convenient first in - first out stock rotating. Choose the quantity of levels that best fits your application. Each level includes four (4) pairs of rollers and each level also includes five divider sections. Units can be bolted together for additional depth. Features: Gravity fed rollers make box removal easy Convenient stock rotation is first in - first out Four pairs of rollers allow boxes to roll easily

High Capacity Reel Rack 96"H Starter Unit Adjustable for up to 60" diameter reels. Axle brackets accommodate up to 2" diameter axles for 2000 lb. capacity per pair. Safety pins lock axle brackets and cross beams to upright frames. Durable 12 gauge steel upright frames measure 3-1/2"W x 3"D. 10 gauge steel axle brackets. Lapped and welded beams have three hooks for positive connection. Cross beams and brackets adjust on 3" centers. Reel rack includes 2 upright frames with built-in brace set, 2 pairs of cross beams, 4 pairs of axle brackets. Rack should be secured to floor. Gray powder coat ...

Reel Racks are built to withstand the abuse and punishment found in a manufacturing or distribution environment. Store and dispense poly or wire rope, hose, electrical cable or chain - anything on a reel or spool. Double welded upright are manufactured from hefty 3" structural channel and welded to a 4" channel base. 96" unites have 3 pairs of axle brackets, 120" and 144" units have 4 pairs (additional brackets may be ordered separately). The special axle brackets are adjustable on 2" centers up and down on the uprights; brackets accept axles up to 2 1/2" diameter. It is strongly ...

BAR STOCK STORAGE RACKS Single Sided Starter Rack Conveniently store bars, lumber, pipes and more on one storage system with these bar storage racks. These tree-like storage racks include 2 uprights and one set of bracing for strength and rigidity. Bar storage racks are made of durable steel with blue painted enamel finish. Varying length arms store different sized and length materials. Withstands capacities up to 2,000 lbs. per level; 500 lb. capacity per arm. Lumber storage racks have 10" height clearance between arms. Measures 84"W x 39"D x 81"H overall. Starter Rack includes 2 ...

LBPH-77, Heavy Duty Bar Storage Rack A highly cost effective way to store up 15,400 lbs. of bar stock, pipe or other long, heavy items. Includes 5 levels of graduated size vertically by 3 sections across. Easy Assembly. Welded steel with blue powder coat finish. Add-On Units adds 7700 lbs. of capacity and 48" in length to Starter Rack.
