Andre SHA-015 - Spring Hangers 2-1/8"L x 1-1/2"W x 2-3/4"H

An excellent general purpose double deflection LDS Rubber hanger for ceiling suspended mechanical equipment and piping. LDS (Low Dynamic Stiffness) Rubber is a special Natural Rubber compound known for its excellent aging characteristics. This hanger is most effective for reducing noise transmission and vibration from equipment running above 1000 rpm. When the location is critical or greater vibration reduction is important, refer to Spring Vibration Isolation Hangers. Max Load 190-380 LBS. 3-1/4"L x 4-1/5"W x 4-1/2"H Overall Dimensions.

Steel spring reduces vibration transmissions most efficiently as performance improves with larger deflections. Spring deflections are 2 - 6 times better than the rubber products. Hangers have LDS Rubber cups under the springs and a projecting rubber bushing prevent sound transmission, even if hanger rods are not perfectly centered. Max Load 130-200 LBS. 2-3/4"L x 3-3/4"W x 5-3/4"H Overall Dimensions.

Rubber EVA Pads are designed to reduce problems in industry caused by vibrations and structure borne noise. EVA foam with ribbed pads on either side provides additional isolation and positive grip. Features: Alternate High-Low Rib construction Excellent sound attenuation capability Simple field installation Suitable for outdoor applications

Features: Waffle Design: In-built suction cups Design allows for easy cutting Simple field installation Application: Where bolting is to be avoided Minor, non-critical vibration conditions Used for Pumps, Motors, AC Units, Generators etc. Recommended for acoustic problem Applications

Features: Simple field installation Waffle Design: In-built suction cups No bolting required Waffle pattern provides superior vibration attenuation Application: Pumps Motors Air-conditioning units Generators Fans
