Mitutoyo 2416A Dial Indicators

Features: iP54 protective rating: Moisture and dust resistance Absolute encoding technology Memorize absolute origin zero Ultra-Response measure speed Inch/Metric conversion Resolution: 0.0005"/0.01 mm High contrast LCD display 330° display rotation Preset and tolerance function Stem dia.: 3/8 Thread size: #4-48 Ceramic contact point Attachable finger lever included(except for 0 - 0.5" sizes) Lug and flat back included SPC/USB data output Battery: 3V CR2032 included Smart Wireless Data Output connects to Bluetooth device

Our digital Indicator offer easy reading, super precision, with both Inch and Metric Measurements. Features: Extra large digits display Analog bar display with adjustable range and tolerance indicators Fast visual indication whether out of pre-set tolerance or not Fast to read max./min. measurement Stem diameter 3/8" TIR function Zero-set for comparison measurements (Floating zero) Inch/Metric Conversion Range: 0 - 1" / 0 - 25.4mm Accuracy: +/- 0.0005" Repeatability: 0.0005" Resolution: 0.0005" / 0.01mm Super large LCD screen Optional lug back plate included Instructions included

The Mahr MarTest 800 V (4302200) delivers precision measurement with ±0.4mm range and 0.01mm graduation. Vertical dial orientation provides clear readings during setup and inspection. High-contrast dial face sealed with O-ring resists coolant and debris ingress. Mineral glass viewing panel protects against scratching and hot shavings. Matt chrome-plated casing with three integrated dovetail guide rails. Shockproof mechanism with 8 jeweled bearings. DIN 2270 compliant. Includes 2mm carbide stylus, mounting shaft, and case.

The Mahr MarTest 800 S (4305200) provides versatile measurement capability with ±0.4mm range and 0.01mm graduation. Computer-optimized shockproof mechanism ensures accuracy and durability. High-contrast dial face with O-ring seal resists liquid penetration. Mineral glass viewing panel offers protection against scratching, hot shavings, and solvents. Matt chrome-plated casing with three dovetail guide rails for flexible mounting. Anti-magnetic design with overload protection via friction clutch. DIN 2270 compliant. Includes 2mm stylus, mounting shaft, test certificate, and case.

Features: Length: 6 7/8" Shank dia.: 3/8" x 7/8" long Feeler dia.: 1/8" Measuring range: 0.25" of axis Dial reading: 0 - 50 Graduation: 0.0005" Includes 6 Feelers: 4", 8", 12" Straight 4", 8", 12" Curved Capacity: 5/32" - 4 1/4" internal 0 - 4 1/4" external Locating accuracy is 0.0005" of center Operates at any angle from horizontal to vertical without any change, and from internal to external by simply changing the feeler Supplied in a fitted wood case This set includes: Indicator body, restraining rod (prevents rotation), spring-loaded center point feeler, three straight feelers (for ...
