Features:
- 12000 watt low frequency inverter 110/220Vac Split Phase
- 36000 watt surge for 20 seconds -3x surge capability
- Battery Priority Selector
- Terminal Block
- Marine Coated and Protected
- Multi Stage Smart charger 80 Amp
- remote panel available
- auto gen start
- 10msec typical transfer time
- optional 25W power save mode
- 8 battery charger settings
Inverter Output Specifications:
- Continuous Output Power: 12000 Watts
- Surge Rating: 30000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- 100-110-120Vac / 220-230-240Vac
- Nominal Efficiency: >88% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: < 10% DC
Input Specifications:
- Nominal Input Voltage: 48.0Vdc
- Low Battery Alarm: 42.0Vdc-44.0Vdc
- Low battery Trip: 40.0Vdc-42.0Vdc
- High Voltage Alarm: 64.0Vdc
- Low battery Voltage Restart: 62.0Vdc
- Idle Consumption: 4.16 amps DC
- Power Saver Mode Idle Consumption: <0.83 amps DC
Charger Specifications:
- Output voltage: Depends on battery Type
- Charger Rate: 120A
Dimensions
- Unit Weight: 154 lbs.
- Unit Size L x W x H: 23.3 x 16.3 x 7.9 inches
- Shipping Weight: 184 lbs.
- Shipping L x W x H 30 x 21.3 x 16.1 inches
