This AIMS power inverter charger is capable of accepting any source of 120v AC power to charge batteries, including a gas or diesel generator or shore power at an RV park/truck stop. It will even accept power from an extension cord plugged into your wall outlet at home. This inverter charger is capable of a 6000 watt surge for 20 seconds and can run at 2000 watts continuously. It works with type-A plugs or a direct 3-wire terminal connection. This inverter comes with a dual-plug GFCI outlet with a reset button. This inverter will never completely drain your batteries as it's low-voltage shut-down keeps the voltage at either 10 volts or 10.5 volts depending on your selection. With the battery priority mode, you can set your inverter to run directly off of a battery back-up system instead of a generator or tertiary source of AC Power.
The inverter charger comes with a power saver mode that pulses every 30 seconds, attempting to detect a necessary load of 25 watts or more before it will turn on. Otherwise, the inverter will "sleep" and draw right around a half an amp per hour, saving you precious reserve power in your batteries until you need it.
Features:
- 2000 watt low frequency inverter
- 6000 watt surge for 20 seconds -3x surge capability
- Battery Priority Selector
- Terminal Block
- GFCI - 15 amps
- Marine Coated and Protected
- Multi Stage Smart charger 70 Amp
- Remote panel available
- Auto gen start
- Auto frequency
- 10msec typical transfer time
- 7 battery type settings for charger
- Sselectable 25W power save mode (hibernation)
- ETL Listed to UL 458 Standards and CSA 22.2 No 107.1
- Continuous Output Power: 2000 Watts
- Surge Rating: 6000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Output Voltage: 100-110-120Vac
- Nominal Efficiency: >92% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- Bypass terminal breaker-30 amps
- THD: < 10% DC
- Nominal Input Voltage: 12.0Vdc
- Minimum Start Voltage: 10.0Vdc
- Low Battery Alarm: 10.5Vdc-11.0Vdc
- Low battery Trip: 10.0Vdc-10.5Vdc
- High Voltage Alarm: 16.0Vdc
- Low battery Voltage Restart: 13.0Vdc
- Idle Consumption: 28 watts
- Charger breaker-20 amps
- Power Saver Mode Idle Consumption: <12.7 watts
- Output voltage: Depends on battery type
- Charger Rate: 70A
- Unit Size L x W x H: 15.35"x 11"x 7"
- Shipping L x W x H: 20.5"X 13.8"X 12.2"
- Unit Weight: 47.4 lbs.
- Shipping Weight: 55 lbs.
