Features:
- 2000 watt low frequency inverter
- 6000 watt surge for 20 seconds 300% surge capability
- Battery Priority Selector
- Terminal Block
- Marine Coated and Protected
- Multi Stage Smart charger 40 Amp
- remote panel available
- auto frequency
- 10msec typical transfer time
- optional 25W power save mode
- 7 battery type settings for charger
Inverter Output Specifications:
- Continuous Output Power: 2000 Watts
- Surge Rating: 6000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Nominal Efficiency: >88% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: < 10% DC
Input Specifications:
- Nominal Input Voltage: 48.0Vdc
- Minimum Start Voltage: 40.0Vdc
- Low Battery Alarm: 42.0Vdc-44.0Vdc
- Low battery Trip: 40.0Vdc-42.0Vdc
- High Voltage Alarm: 64.0Vdc
- Low battery Voltage Restart: 62.0Vdc
- Idle Consumption: <1.25 amps DC
- Power Saver Mode Idle Consumption: <1 amps AC
Charger Specifications:
- Output voltage: Depends on battery Type
- Charger Rate: 15A
- Over Charge Protection Shutdown 62.8V
- Selectable Charge setting based on battery type
- Adjustable charge current off-20%-100%
- Four Stage Smart Charger
Transfer Switch Specifications:
- 30 amp automatic transfer switch
- 10 ms (max)
Dimensions
- Unit Weight: 44 lbs.
- Unit Size L x W x H: 17.40 x 8.59 x 7.05 inches
- Shipping Weight: 47 lbs.
- Shipping L x W x H 22.83 x 12.40 x 11.81 inches
