80/20 3362 Anchor Fastener

The double anchor slide-in T-nut is used with a double anchor fastener. It loads from the profile end and is a strong, durable connection. There are options available in size, thread, and finish. Important Note: The double anchor slide-in T-nut can only be used with a double anchor fastener.

80/20 3795 Double End Fastener Double Wing Clip Features: Provides a clean, hidden method of connecting profiles at 90° without the use of joining plates Winged tabs of clip prevent mating profile from rotating Mounting profile requires an end tap; mating profile requires an access hole to reach the screw head

The butt fastener assembly is comprised of a bolt and two cams. The butt fastener connects profiles end-to-end and provides a clean, flush connection, especially convenient where space restrictions apply. The butt fastener can also be used to connect shorter bars together where logistics or space makes it difficult to maneuver longer profiles. This connection method requires a counterbore machining service on each profile. TIP: Butt Fastener Machining will need to be added to the profile when ordering.

The wing clip is commonly used with a button head socket cap screw to create custom end fastener assemblies. The winged tabs of the clip prevent the mating profile from rotating. An end fastener connection method requires two machining services; an end tap on the mounting profile and an access hole in the mating profile in order to reach the screw head.

80/20 3183 End Fastener Single Wing Clip Features: Provides a clean, hidden method of connecting closed-sided and quarter round profiles at 90° without the use of joining plates Winged tab of clip prevents mating profile from rotating The mounting profile requires an end tap; mating profile requires an access hole to reach the screw head
