Terrier 4 TDH Horizontal Plate Lifting Clamp, 4400 lb. Capacity, 2"Jaw

For vertical lifting, transporting and turning of all steel plates with a hardness of max. 55 HRC. Please ask for special specifications. Features: Equipped with an extra hardened pivot and cam Cam is colored green for easy identification Always equipped with a safety mechanism, ensuring the clamp does not slip when lifting force is applied and when load is being lowered Clamp is locked in closed as well as open position Lightweight design for easy handling Tough quality heavy duty welded shell body 4.5 TSEU-H Hard Vertical Plate Lifting Clamp with 0-1.77 inch jaw opening & 9900 lbs ...

For vertical lifting and transporting of all plates and structures without marking, scratching and or damaging the material surface Features: With 2 special synthetic anti-friction pads to guarantee non-marking Supplied with chain lifting shackle for flexible lifting Always equipped with a safety mechanism, ensuring the clamp does not slip when non-marking lifting force is applied and when load is being lowered Clamp is locked in closed as well as open position Lightweight, maintenance-friendly, heavy duty body 0.5 TNMK Vertical Plate Lifting Clamp with 0-.78 inch jaw opening & 1100 lbs ...

For horizontal lifting and transporting of steel plates and other non-deflecting materials Features: Compact design and high lifting capacity Horizontal lifting clamps should always be used with a minimum of two pieces The given WLL is valid per pair 3 FHX Horizontal Plate Lifting Clamp with 0-2.36 inch jaw opening & 3300 lbs Working Load Limit

Terrier 4 TNMH Non-Marking Horizontal Lifting Clamp is designed for safe horizontal lifting and transport of plates and materials without scratching, denting, or damaging finished surfaces. Ideal for stainless steel, aluminum, painted materials, composites, glass, and plastics, it features protective jaw pads, rugged construction, and a lifting capacity of 8,800 lb per pair when used correctly.

For vertical lifting, transporting and turning of stainless steel plates and structures. Note: The plate surface of the material must have a hardness level of max. HRC 37/345 Hb Features: Pivot and cam are made of stainless steel Body and lock lever are nickel plated to prevent corrosion due to carbon contamination TSU-R / TSEU-R come with articulated lifting shackle for universal lifting flexibility at various angles TS-R / TSE-R come with standard lifting shackle Always equipped with a safety mechanism, ensuring the clamp does not slip when Lifting force is applied and when load is ...
