Global Industrial™ Pipe Fitting - Crossover 1-1/4" Dia.

Global Pipe Fitting - 90 Degree Two Socket Tee 1" Diameter 90 Degree Two Socket Tee Pipe Fitting provides a corner joint for the middle rail of guard railing and other pipe-based structures. Upright passes through the socket tee for precise placement of the middle rail. Strong iron material includes a galvanized finish for corrosion resistance and long term use. Fitting locks onto 1" diameter pipe with hardened set screws (included) for secure connection. Anchor hole is slightly larger than ½" diameter.

Kee Klamp® Fittings Crossover Coupling This fitting is designed to give a 90 degree offset crossover. As there are two socket set screws in the sleeve, this Kee Klamp fitting can be used where a join is required in the horizontal pipe. For economy, it is possible to use a Type 45 in place of the 145, using the 145 only where a join in the pipe occurs. When calculating the cutting lengths for pipe, dimension 'G' should be added to give the pipe length for the upright.

Global Pipe Fitting - Rail Flange 1-1/2" Diameter Rail Flange Pipe Fitting is commonly used to mount hand rail, guard rail or other pipe-based structures to the floor. Durably constructed of galvanized iron to provide maximum corrosion resistance and long lasting durability. Rail flange includes two hardened set screws in the vertical socket for greater side load stability. For safe installation, flange fixing holes should be in line with the applied load. For 1-1/2" diameter pipe. Anchor hole is slightly larger than ½" diameter.

Global Pipe Fitting - Side Outlet Tee 1-1/4" Diameter Side Outlet Tee Pipe Fitting is frequently used to join an upright with three horizontal pipes when building racking, structural framework or hand rail systems. Upright passes through the side outlet tee for precise placement of each horizontal rail. Pipe fittings are made from galvanized iron for long lasting durability and corrosion resistance. Fitting locks onto 1-1/4" diameter pipe with hardened set screws (included) for secure connection. Anchor hole is slightly larger than ½" diameter.

Kee Klamp® Fittings Tee & Crossover Used on racking to join horizontal carrying rails to the upright, leaving the socket to take a horizontal tie across the section. For shelved racking it is usual to have the horizontal pipe outside the upright. On pallet racking it is preferable to have the carrying rails inside the upright.
