iGAGING Absolute Origin Indicator w/ 1" Range & 0.0005" Accuracy

iGAGING® Premium Extended Range Test Indicator Features: Range: 0.060" IP67 protective rating: Water and coolant proof US PATENTED Graduation: 0.0005" Reading: 0-15-0 Face dia.: 1 1/2" Satin chrome fi nish Universal positioning contact 2-side standard dovetail mount Jeweled movement Meet or exceed Federal specifi cations 3/8" & 5/32" dovetail stems included Contact point: 0.080" dia x 1/2" length Supplied in protective case.

Features: iP54 protective rating: Moisture and dust resistance Absolute encoding technology Memorize absolute origin zero Ultra-Response measure speed Inch/Metric conversion Resolution: 0.0005"/0.01 mm High contrast LCD display 330° display rotation Preset and tolerance function Stem dia.: 3/8 Thread size: #4-48 Ceramic contact point Attachable finger lever included(except for 0 - 0.5" sizes) Lug and flat back included SPC/USB data output Battery: 3V CR2032 included Smart Wireless Data Output connects to Bluetooth device

Features: iP54 protective rating: Moisture and dust resistance Absolute encoding technology Memorize absolute origin zero Ultra-Response measure speed Inch/Metric conversion Resolution: 0.0005"/0.01 mm High contrast LCD display 330° display rotation Preset and tolerance function Stem dia.: 3/8 Thread size: #4-48 Ceramic contact point Attachable finger lever included(except for 0 - 0.5" sizes) Lug and flat back included SPC/USB data output Battery: 3V CR2032 included Smart Wireless Data Output connects to Bluetooth device

Our digital Indicator offer easy reading, super precision, with both Inch and Metric Measurements. Features: Extra large digits display Analog bar display with adjustable range and tolerance indicators Fast visual indication whether out of pre-set tolerance or not Fast to read max./min. measurement Stem diameter 3/8" TIR function Zero-set for comparison measurements (Floating zero) Inch/Metric Conversion Range: 0 - 1" / 0 - 25.4mm Accuracy: +/- 0.0005" Repeatability: 0.0005" Resolution: 0.0005" / 0.01mm Super large LCD screen Optional lug back plate included Instructions included

iGAGING® IP67 HIGH RESOLUTION DIGITAL INDICATORS Features: Range: 0-0.5"/12.7mm Accuracy: 0.0003"/0.007mm IP67 protective rating: Water and coolant proof Absolute encoding technology tracks absolute origin zero Ultra-Response measure speed Inch/Metric conversion Easy to read LCD display Preset and tolerance function +/- measurement direction switch Stem dia.: 3/8" Thread size: #4-48 Carbide contact point Lug and fl at back included Attachable fi nger lever included(except for 0 - 0.5" sizes) Auto shut-off Micro USB data output port(Cable for charging or data output option included) Power: ...
