iGAGING Double Range Test Indicator, 0.06"/0.0005", 3 Contact Points

Features: iP54 protective rating: Moisture and dust resistance Absolute encoding technology Memorize absolute origin zero Ultra-Response measure speed Inch/Metric conversion Resolution: 0.0005"/0.01 mm High contrast LCD display 330° display rotation Preset and tolerance function Stem dia.: 3/8 Thread size: #4-48 Ceramic contact point Attachable finger lever included(except for 0 - 0.5" sizes) Lug and flat back included SPC/USB data output Battery: 3V CR2032 included Smart Wireless Data Output connects to Bluetooth device

Features: iP54 protective rating: Moisture and dust resistance Absolute encoding technology Memorize absolute origin zero Ultra-Response measure speed Inch/Metric conversion Resolution: 0.0005"/0.01 mm High contrast LCD display 330° display rotation Preset and tolerance function Stem dia.: 3/8 Thread size: #4-48 Ceramic contact point Attachable finger lever included(except for 0 - 0.5" sizes) Lug and flat back included SPC/USB data output Battery: 3V CR2032 included Smart Wireless Data Output connects to Bluetooth device

The Mahr MarTest 800 V (4302200) delivers precision measurement with ±0.4mm range and 0.01mm graduation. Vertical dial orientation provides clear readings during setup and inspection. High-contrast dial face sealed with O-ring resists coolant and debris ingress. Mineral glass viewing panel protects against scratching and hot shavings. Matt chrome-plated casing with three integrated dovetail guide rails. Shockproof mechanism with 8 jeweled bearings. DIN 2270 compliant. Includes 2mm carbide stylus, mounting shaft, and case.

The Mahr MarTest 800 SGM (4308200) delivers high-resolution measurement with ±0.1mm range and 0.002mm graduation for precision applications. 38mm dial diameter provides enhanced readability. Error limit of 3μm with 2μm hysteresis ensures accuracy. High-contrast dial face with O-ring seal and mineral glass viewing panel resist damage and solvent exposure. Matt chrome-plated casing with three dovetail guide rails. Shockproof mechanism with 0.15N measuring force. DIN 2270 compliant. Includes 2mm stylus, mounting shaft, test certificate, and case.

The Mahr MarTest 800 S (4305200) provides versatile measurement capability with ±0.4mm range and 0.01mm graduation. Computer-optimized shockproof mechanism ensures accuracy and durability. High-contrast dial face with O-ring seal resists liquid penetration. Mineral glass viewing panel offers protection against scratching, hot shavings, and solvents. Matt chrome-plated casing with three dovetail guide rails for flexible mounting. Anti-magnetic design with overload protection via friction clutch. DIN 2270 compliant. Includes 2mm stylus, mounting shaft, test certificate, and case.
