Marathon Motors Multi-Speed Motor, Y418, 254TTDX7208, 7-1/2 - 3 1/3HP, 1800/1200RPM, 460V, 3PH

Marathon Motors Multi-Speed Motor, Y418, 254TTDX7208, 7-1/2 - 3 1/3HP, 1800/1200RPM, 460V, 3PH

Item #: WBB868158

Not Yet Rated

Enter zip code for delivery date estimate

Shipping to 10465 change

Price: $2,345.00

$390.83/mo suggested payments with 6 month special financing OR Save 5%on Purchase.

Quantity

Customers Also Viewed

Marathon Motors Multi-Speed Motor, Y1484, 182TTDW7412, 3 - 3/4HP, 1800/900RPM, 200-230V, 3PH

Marathon Motors Multi-Speed Motor, Y1484, 182TTDW7412, 3 - 3/4HP, 1800/900RPM, 200-230V, 3PH

Stainless Steel Straight Leg Slotted Shim 260-Piece Full Kit w/ Box - Size B - Made In USA

Stainless Steel Straight Leg Slotted Shim 260-Piece Full Kit w/ Box - Size B - Made In USA

Marathon Motors Multi-Speed Motor, Y465, 145TTDR5701, 1 - 1/4HP, 1800/900RPM, 460V, 3PH

Marathon Motors Multi-Speed Motor, Y465, 145TTDR5701, 1 - 1/4HP, 1800/900RPM, 460V, 3PH

Leeson Motors 3-Phase Multi-Speed Motor 1/.25HP, 1725/850RPM, 143, TEFC, 60HZ, 40C, 1.0SF, Rigid

Leeson Motors 3-Phase Multi-Speed Motor 1/.25HP, 1725/850RPM, 143, TEFC, 60HZ, 40C, 1.0SF, Rigid

Leeson Motors 3-Phase Multi-Speed Motor 1/.5HP, 1725/850RPM, 143, TEFC, 60HZ, 40C, 1.0SF, Rigid

Leeson Motors 3-Phase Multi-Speed Motor 1/.5HP, 1725/850RPM, 143, TEFC, 60HZ, 40C, 1.0SF, Rigid

Global Industrial™ Outdoor Ashtray, 1-1/2 Gallon, Black

Global Industrial™ Outdoor Ashtray, 1-1/2 Gallon, Black

Free Shipping

Stainless Steel Straight Leg Slotted Shim 130-Piece Tool Crib Kit w/ Box - Size B - Made In USA

Stainless Steel Straight Leg Slotted Shim 130-Piece Tool Crib Kit w/ Box - Size B - Made In USA

Marathon Motors Multi-Speed Motor, Y418, 254TTDX7208, 7-1/2 - 3 1/3HP, 1800/1200RPM, 460V, 3PH

Commercial and industrial fans, blowers, pumps, and other machinery that have variable torque characteristics. Prolonged use at low speed can result in significant energy saving. Dripproof motors are intended for use in environments that are relatively clean and dry.

Product Details

  • High Speed Full Load Amps 10 FLA
  • High Speed SF 1.15
  • Mounting Location Rigid
  • Bearing Drive End Ball
  • Low Speed Voltage 460 V
  • Assembly Required F1 (F2 Modification Available)
  • Low Speed FL EFF 0.775
  • RPM 1800/1200 rpm
  • High Speed kW 5.6 kW
  • Ambient Temperature 40 °C
  • Low Speed Full Load Amps 5.6 FLA
  • Low Speed FL SF 1.15
  • KVA Code H
  • Low Speed RPM 1200 rpm
  • IP Code 12
  • Low Speed Horsepower 3 1/3 HP
  • Insulation Class B
  • RPM Range 1701-1800 rpm
  • Voltage 460 V
  • Frame 254T
  • Low Speed 2.48
  • Horsepower 7-1/2 HP
  • Enclosure Type Open/Drip Proof
  • Is_Motor Yes
  • Duty Continuous
  • Enclosure DP
  • Phase 3
  • Orientation Horizontal
  • Starting Type Across the Line
  • Brand Marathon Motors
  • High Speed Full Efficiency 0.84
  • Motor RPM 60 Hertz 1800 rpm
  • Manufacturers Part Number Y418
  • Catalog Number Y418

Compliance & Certifications

  • NEMA Design 2VT
  • CSA Certified Y
  • UL Recognized Construction

Weights & Dimensions

  • Drive End Bearing Size 6309
  • Opposite End Bearing Size Ball
  • Weight 154 lbs
