The drum is pre-wrapped with 80 grit sandpaper. Additional accessories and sandpaper are available for purchase.
Features:
- 25" Sanding In A Single Pass, 50" In A Double Pass
- More Room For Easy Access To Abrasives – No Special Tool Needed
- Flatter head installed on machine for sanding uneven surfaces
- Aluminum drum included for drum sanding
- Open Stand included
- Variable Feed Speed with INTELLISAND®
- Variable head speed needed when using brush heads
- Optional Wire and Nylon brush heads available for purchase
- Simple alignment feature - Just one nut will adjust the conveyor to parallel the sanding head, making aligning the conveyor to the sanding head fast and easy
- Indexed Alignment Setting – Has an indexed alignment setting for narrow and wide stock. When sanding stock wider than 25", the index lever will properly adjust the conveyor for flawless wide sanding
- Drum Will Never Go "Out Of Alignment" – The drum carriage is bolted to the base, preventing any movement or alignment issues
- INTELLISAND® Technology: Automatically adjusts conveyor speed based on load
- Prevents gouging, damaging or burning stock
- Provides consistent finish even with varying grain pattern and density
- Greatly increases abrasive planing and dimensioning speed
- Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no "flex" in conveyor, guaranteeing flatness to less than .010" across the width of the sander
- Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
- Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
- Easiest access to abrasive fastening system of any drum sander! Extra wide space to access fasteners to eliminate need for special tools
- Self-cooling drum prevents overheating and extends abrasive life
- Tension rollers are adjustable in height and hold down pressure, eliminating snipe
- Excellent dust extraction as dust cover is formed to shape of drum: Metal, not plastic, is formed to maximize air flow and dust extraction
- Heavy-duty cast iron construction for strength, rigidity and reduced vibration
- Mobile base allows for stand and machine to be to moved easily
- Maximum Sanding Width: 50" (Two Passes)
- Minimum Sanding Length: 2-1/2"
- Maximum Sanding Thickness: 4"
- Minimum Sanding Thickness: 1/32"
- Dimensions (D x W x H): 27" x 46" x 53" (On Stand)
- Drum: 5" x 25" Extruded Aluminum
- Drum Speed: 1740 RPM
- Dust Hood: 1 – 4" Vacuum Port, Min. 600 CFM Recommended
- Conveyor Motor: 43 in.-lb. torque, direct drive D.C. motor, ranged variable 0-10 FPM
- Drive Motor (TEFC): 1-3/4 HP
- Power Requirements: 110 V 20 amp
- Table Height (Floor To Top Of Table): 33"
