Features:
- MPPT technology: Maximum Power Point Tracking produces maximum available power from PV array to battery bank utilizing peak power of the I-V curve
- Quality heatsink cooling no fans needed and no thermal derating
- Battery type selector and user defined charging voltage
- 4 stage charging
- Includes battery temperature sensor
- PV input, battery output and DC load control ports
- Stackable
- Reliable electronics, over engineered components generating less heat
- Very efficient up to 99%
- Low self consumption
- Optimal cooling case design-built for extreme conditions
- Over temp protection
- Overload, short circuit, high and low voltage protection
- RS485 port for computer monitoring (not included on the 30amp)
- CE, ETL to UL1471 and RoHS compliant
- Conformal coated for marine environments
- Mounting holes
- PV Operating Voltage: 15-155Vdc@12V, 34-155Vdc@24V, 50-155Vdc@36V, 60-155Vdc@48V
- Rated PV input: 12V-800 Watts, 24V-1700 watts, 36V-2400 watts, 48V-3400 watts
- Maximum battery current: 60 amps
- Max PV open circuit voltage: 155Vdc
- Self power consumption: <4 watts
- Protections: overload, short circuit, high voltage, high temperature, low voltage and auto correct
- Battery types: gel, sealed, AGM, flooded, lithium, user defined (adjustable voltage)
- 4 Stage charging: bulk, absorption, float and equalize
- Bulk charge voltage: sealed 14.4V, AGM/gel 14.2V, flooded 14.6V, user defined 10-15V
- Float charge voltage: sealed/AGM/gel 13.7V, flooded 13.6V, user defined 10-15V
- Equalize charge voltage: sealed 14.6V, AGM/gel 14.8V, flooded 14.8V, user defined 10-15V
- Low voltage reconnection: 12.5V
- Low voltage disconnect voltage: 10.5V (10.5-12.5V adjustable)
- Enclosure: IP43 protection, metal
- H
- Humidity:100% non-condensing
- Temperature compensation: -5mV°C / 2V with BTS
- Temperature range: -25°C to 60°C or -13°F to 140°F
- Wire knockouts: 1.25"
- Unit weight: 15.5 lbs, Boxed weight: 17.5 lbs
- Dimensions: 14.5"L x 10.5"W x 4.5"H
- Warranty: 2 years
