Microscope Features:
- 30 degree inclined 360 degree swiveling Siedentopf binocular head
- High quality precise optical glass elements
- Easy attachment of microscope cameras or digital imagers
- Eight magnification settings, 40X-80X-100X-200X-400X-800X-1000X-2000X
- Four Achromatic objectives, DIN 4X, 10X, 40X(S), 100X(S, Oil)
- Two pairs of widefield eyepieces: WF10X and WF20X
- Adjustable interpupillary distance
- Adjustable ocular diopter
- Variable intensity illumination
- Coaxial coarse and fine focus adjustment
- Focusing knobs are on both sides of the microscope
- Stage upward moving lock protects objectives and slides
- Stain-resistant double layer mechanical stage
- NA1.25 Abbe Condenser with iris diaphragm & filters
- Rack and pinion adjustment condenser
- Manufactured Under ISO 9001 Quality Control Standard
- Excellent Five (5) Year Factory Warranty
- Eyepieces: widefield, WF10X and WF20X
- Objectives: Achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil)
- Head: 30 degree inclined 360 degree swiveling binocular
- Interpupillary distance: 2-1/8" - 3-1/8" (53mm - 77mm)
- Adjustable ocular diopter
- Nosepiece: revolving quadruple
- Mechanical Stage: 3-D double layer
- Size: 4-5/8" x 5" (118mm x 127mm)
- Travel Range (X-Y): 2-13/16" x 1-3/16" (70mm x 30mm)
- Condenser: NA1.25 Abbe condenser with iris diaphragm
- Illumination: LED light, transmitted, intensity adjustable, GS and CE approved
- Focusing: coaxial coarse & fine knobs on both sides
- Power Supply: 100-240VAC, 50/60Hz, AC/DC adapter (UL approved) Included
- Dimension: 11" x 7" x 13-3/4" (280mm x 178mm x 350mm)
- Sensor: Aptina MT9J003
- Sensor Type: CMOS
- Sensor Size: 6.44x4.616mm
- Pixel Size: 1.67
- Resolution: 10.0MP
- Frame Rate: 1.9@3584x2748, 8@1792x1374, 27@896x684
- Sensitivity: 0.31 V/lux-sec
- Compatibility: Windows (32/64 bit) XP/Vista/7/8/10, Mac OSX, Linux
- OS Requirements: Windows (32/64 bit) XP/Vista/7/8/10, Mac OS 10.8+, Linux kernel 3.13+
- Hardware Requirements: Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0 port
