• Single tier doors have 3-point locking device (top, bottom, and center) PERSONNEL LOCKERS
• Double tier doors have 2-point locking device (top and bottom)
• Trouble-free, right hand butt hinge is recessed in door frame;
pin cannot be forced out Tough Enough to Last for Decades
• Rubber cushions on doors eliminate metallic sound
• Tamper proof chrome handle for smooth fingertip operation
• Legs add 6’’ to overall height, number plate included. Specify number at time of
order, otherwise start with #1.
• For safety, anchoring lockers to floor and/or wall is recommended
• Single and Double Tier are available in Recessed Handle or Pull Latch Handle, Triple
Tiers are available in Recessed Handle or Friction Latch Handle all at the same price.
Add Suffix “R” before the color suffix when ordering the Recessed Handle Lockers.
Example: SG480700RGY
• Powder coat finishes; specify color suffix: Gray (GY), Champagne (CA), Marine Blue
(MB), and Burgundy (BY)
• Assembled lockers are not returnable
• 3 48 Hours Quick Ship available for ready to assemble in Champagne and Gray in
Single, Double, Triple in Recessed Handle lockers and Six Tier, 16 person Lockers
A. SINGLE TIER. Shelf 9’’ from top for hats, lunches, etc. Includes coat
hooks on 12’’ and 15’’ deep and a coat rod on 18” deep lockers.
READY TO ASSEMBLE ASSEMBLED
Opening Overall Wt. Price/ Price/
W”x D”x H” Width Doors Lbs. Model Group Model Group
12 x 12 x 60 12 1 50 SG480700 $145.00 SG480000 $175.00
12 x 12 x 60 36 3 126 SG480702 362.00 SG480007 444.00
12 x 15 x 60 12 1 52 SG480704 150.00 SG480001 180.00
12 x 15 x 60 36 3 135 SG480706 375.00 SG480008 458.00
12 x 18 x 60 12 1 57 SG480708 160.00 SG480002 189.00
12 x 18 x 60 36 3 141 SG480710 395.00 SG480009 479.00
12 x 12 x 72 12 1 57 SG480709 159.00 SG480933 188.00
12 x 12 x 72 36 3 150 SG480711 394.00 SG480940 478.00
12 x 15 x 72 12 1 65 SG480713 165.00 SG480936 194.00
12 x 15 x 72 36 3 156 SG480715 409.00 SG480938 491.00
12 x 18 x 72 12 1 69 SG480712 173.00 SG480934 202.00
12 x 18 x 72 36 3 165 SG480714 429.00 SG480911 512.00 B A
15 x 18 x 72 15 1 71 SG480716 188.00 SG480005 217.00 TRIPLE
15 x 18 x 72 45 3 195 SG480718 466.00 SG480912 549.00 C
18 x 18 x 72 18 1 83 SG480720 199.00 SG480006 228.00 SINGLE
18 x 18 x 72 54 3 219 SG480722 508.00 SG480913 580.00
B. DOUBLE TIER. Includes coat hook. Add 6” to height for legs.
12 x 12 x 30 12 2 52 SG480726 $184.00 SG480944 $214.00
12 x 12 x 30 36 6 126 SG480728 459.00 SG480946 543.00
12 x 12 x 36 12 2 56 SG480730 194.00 SG480014 222.00 GRAY
12 x 12 x 36 36 6 150 SG480732 480.00 SG480917 567.00
12 x 15 x 36 12 2 62 SG480734 202.00 SG480015 230.00
12 x 15 x 36 36 6 156 SG480736 501.00 SG480918 585.00 CHAMPAGNE PULL LATCH FRICTION LATCH STAINLESS
12 x 18 x 36 12 2 66 SG480738 210.00 SG480016 238.00 HANDLE AND HASP STEEL
12 x 18 x 36 36 6 168 SG480740 520.00 SG480919 602.00 RECESSED
C.TRIPLE TIER. Includes coat hooks. BURGUNDY HANDLE
12 x 12 x 24 12 3 51 SG255236 $196.00 SG480108 $226.00
12 x 12 x 24 36 9 144 SG255237 490.00 SG480109 574.00
12 x 15 x 24 12 3 57 SG255238 202.00 SG480110 233.00 MARINE BLUE
12 x 15 x 24 36 9 162 SG255239 503.00 SG480111 587.00
D. TWO PERSON. Each 7 /2’’W x 53’’H lower door controls operation of
1
one 9 /2’’H upper compartment. Coat rod on 18’’ and 21’’D lockers. D E
1
Hooks on 15’’D. 15’’W x 72’’H overall, add 6’’ to height for legs. Ships
ready to assemble.
ONE WIDE (2 Persons) THREE WIDE (6 Persons)
Depth’’ Model Price Model Price
15 SG480171 $322.00 SG480173 $801.00
18 SG480175 345.00 SG480177 862.00
21 SG480179 366.00 SG480181 909.00
F. 16 PERSON.
E. SIX TIER. Padlockable friction latch and hasp closure, add 6” to height for legs. 12”W x 18”D x
READY TO ASSEMBLE ASSEMBLED 12”H compartments
Opening Overall Wt. Price/ Price/ 72”W x 18”D x
W”x D”x H” Width Doors Lbs. Model Group Model Group 72”H 78”H overall.
12 x 12 x 12 12 6 54 SG480750 $264.00 SG480954 $260.00
12 x 12 x 12 36 18 162 SG480752 547.00 SG480955 655.00
12 x 15 x 12 12 6 54 SG480754 226.00 SG480956 267.00 F READY TO
12 x 15 x 12 36 18 162 SG480756 562.00 SG480957 661.00 ASSEMBLE
Model Price
Locks Model Price SG480770 $639.00
Master Lock ® 1525 Comb. Padlock w/key access SG652975 $7.00 ASSEMBLED
Master Lock ® Built-in Combo Lock
Single / Double/Triple Tier #1630 SG652864D 13.00 Model Price
Six/Sixteen Person #1670 SG652868 6.00 SG480771 $742.00
Keyed Padlock w/2 keys SG959101 6.00
See Page 72 for Selection of Locker Benches
73
