Accurate, User-Friendly Control System
- Runs in single-bend mode or programmable mode
- Comes standard with 2 axes of control: stroke and back gauge distance
- Simple controller is so intuitive that you could train someone to use it in 5 minutes
- Programmer stores up to 40 programs with up to 25 bends per program, great for saving time on production
- Bending is accurate to +/- .01mm, ensuring that parts come out right the first time
- Main electrical components made in Germany by Weidmueller and Schneider will give you years of trouble-free productivity
- Foot pedal brings the stroke up and down. Just input your specs on the controller, then press the pedal for each bend
- You can make a complete part without touching the controller. Push the metal in while pressing the foot pedal
- Choose between 2 speeds: a rapid approach and retract and a slow bending speed
- Speed option lets you reduce cycle time and make your shop more efficient
- Chain drive back gauge system uses tried-and-true technology that you can maintain easily
- The 23-5/8" back gauge can advance or retract according to programmed instructions
- Fully welded all-steel construction helps prevent deformation and minimize flex during the bending process
- Weighs a whopping 14,403 lbs. for massive structural strength that ensures accurate results
- Includes support arms around 2 feet in length
- Comes standard with tooling: a multi-vee bottom die and gooseneck punches (European Style)
- Quick-release tool holders let you make changes easily. Just open a lever and it drops the top die out. No time-consuming cap screws!
- Crowning adjustment dial gives you the option to deliver more pressure in the center of a bend for consistency all the way across
- Safety light curtains prevent the machine from bending when someone is too close
- Light curtains will swing open and get out of the way when you're doing a tool change
- Delivers 112 tons of pressure
- Distance between the housings lets you slide in 8-foot pieces of mild steel
- Runs on 220-volt 3-phase power
- Industrial-grade hydraulic system with a Vickers/Eaton pump will last for many years at peak capacity
- NOK hydraulic seals from Japan are some of the best in the industry. They'll keep the hydraulics running smoothly
- Torque tube connects the 2 hydraulic cylinders, so they always stay synchronized and parallel to the bending table
- Chain drive linkage keeps hydraulic cylinders in time with each other, so the machine stays balanced and lasts longer
- Hydraulic cylinders are near the back of the machine for convenient fluid changes
