This loop calibrator sources and measures mA. The R5820 features a 24V loop power supply, selectable step or ramp outputs and an easy-to-read 5-digit LCD display.
This portable and easy-to-use calibrator provides accurate measurements and calibrations for a wide range of process signals, including voltage, current, resistance, frequency, and temperature.
Features:
- mA sourcing and measurement
- 0-28 VDC measurement to check loop voltage
- Basic measurement/sourcing accuracy of 0.02% and 0.05%, respectively
- Simulate mA and % with 0.001% display span
- Selectable step or ramp outputs
- Internal 24V loop power supply
- Low battery indicator and auto shut off (after 15 mins/off) (Battery Life Approx. 20 hours)
- Storage Temperature: 14 to 122°F (-10 to 50°C)
- Operating Temperature: 32 to 122°F (0 to 50°C)
- Operating Humidity Range: 0 to 85%
- Loop Calibrator
- Test leads
- Alligator clips
- Protective holster
- 2 AA Batteries
- Testing loop powered isolators and two-wire transmitters
- Verifying and calibrating processes involving mA instrumentation
- DC Voltage Measurement:
Range: 28V,Output Range: -0.200 to 28.000V, Resolution: 1mV, Accuracy: ±0.02% reading ± 2mV - DC Current Measurement:
Range: 20mA,Output Range: -1.000 to 22.000mA,Resolution: 0.001mA, Accuracy: ±0.02% reading + 4µA - Loop Current Measurement:
Range: 20mA, Output Range: 0.000 to 22.000mA, Resolution: 0.001mA, Accuracy: ±0.02% reading + 4µA - Current Output:
Range; 20mA,Output Range; 0.000 to 22.000mA, Resolution: 0.001mA, Accuracy: ±0.05% setting + 4µA - Analog Transducer Output:
Range: -20mA, Output Range: 0.000 to -22.000mA, Resolution:0.001mA, Accuracy: ±0.05% setting + 4µA,Loop Power: 24V, Accuracy: ±10%
What's included with the REED R5820:
Ideal Applications for the REED R5820:
