- Overall Dimensions: 24"W x 30"D x 60-7/8"H
- 3 drawers and 4 shelves (2 adjustable and 2 fixed)
- Full-width, polished, color-anodized, extruded aluminum drawer pulls and handle
- Full-extension ball bearing slides allow drawers to open and close smoothly
- Drawer capacities: 150lbs for single slides; 300lbs for double slides
- AkzoNobel high gloss powder coat finish
- Tubular, coded security lock and keys can be keyed to match roller cabinet
- Heavy duty bracket for attaching to roller cabinet eliminates need for casters
- PVC drawer liners included
- Mounts on RX Series 72"W x 30"D or RXQ Series 84"W x 30"D (sold separately)
- Assembly required
- 30" Cabinet depth
- Mounted with support bracket – no casters needed
- Tubular, coded security lock and keys
- Steel Thickness: 2.0mm bottom frame-caster channels; 1.2mm drawer fronts; 1.0mm top/back/side/inner panels; 0.8mm drawer body/reinforcing supports
Outside Dimensions:
- 20-13/16 x 27-3/16 x 2-13/16 (150 lbs. load rating)
- 20-13/16 x 27-3/16 x 5-13/16 (300 lbs. load rating)
- 19-7/8 x 27-1/8 x 2-3/16
- 19-7/8 x 27-1/8 x 5-1/8
- Bottom Panel: 21
- Side Panels: 19
- Inner Panel: 19
- Drawer Back: 21
- Top Panel: 19
- Back Panel: 19
- Top Reinforce Support: 21
- Drawer Front: 18
- Drawer Body: 21
- Caster Channel Gauge: 14
