- True RMS AC voltage and current for accurate measurements on non linear signals
- Backlit keypad buttons
- Large, 2-level, bright white, backlit display
- Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment
- 0.05% DC accuracy
- 6000 counts, 3-3/4 digits
- 4-1/2 digit mode for precise measurements (20,000 counts)
- Measure up to 1000 VAC and DC
- Measure up to 10 A, 20 A for up to 30 seconds
- Built in thermometer lets you carry one less tool (TC probe included)
- Frequency to 200 kHz and % duty cycle
- Resistance, continuity and diode test
- 10,000 µF capacitance range
- Peak capture to record transients as fast as 250 µs
- Relative mode to remove test lead interference from low ohms measurements
- Auto and manual ranging for maximum flexibility
- Touch Hold to capture stable readings
- Analog bargraph for fast changing or unstable signals
- Input Alert provides audible warning against wrong use of input jacks
- Improved selectable sleep mode for long battery life
- Access door for fast battery changes without breaking the calibration seal
- Designed to block potentially hazardous voltages
- Subjected to a 10,000 V dielectric strength test, protection works
- Certified to 1,000 V ac and 1,500 V dc by VDE
- Comply to IEC 60900 and ASTM F1505
- Critical part of NFPA 70E, which requires personal protective equipment and insulated tools rated for electrical installation
- Insulated Screwdrivers
- Ergonomic handle that adapts to user's hand, causes less strain and work fatigue and provides maximum torque
- Slim insulated shaft allows access in hard-to-reach areas
- Manufactured from CMV steel for superior durability
- Size: #1
- Blade length: 3 in., 75 mm
- Handle length: 3 11/16 in., 94 mm
- Shaft diameter: 7/32 in., 5.5 mm
- Size: #2
- Blade length: 4 in., 100 mm
- Handle length: 4 3/16 in., 106 mm
- Shaft diameter: 1/4 in., 6 mm
- Blade length: 3 in., 75 mm
- Handle length: 3 3/8 in., 86 mm
- Shaft diameter: 3/32 in., 2.5 mm
- Blade length: 4 in., 100 mm
- Handle length: 3 11/16 in., 94 mm
- Shaft diameter: 5/32 in., 4 mm
- Blade length: 5 in., 125 mm
- Handle length: 4 3/16 in., 106 mm
- Shaft diameter: 1/4 in., 6 mm
- Insulated Pliers
- Nominal length: 8 in., 200 mm
- Secure hold by aggressive serrated jaws and 4-point gripping hole
- Slim shape for better access to wires in tight spaces
- Powerful gripping jaw, yet very light
- Nominal length: 8 in., 200 mm
- Cuts hard materials including steel and piano wire
- Power joint and precision cutting edges
- Nominal length: 8 in., 200 mm
- Unique milled wave pattern gripping zones
- 4 gripping points for pulling round objects with superior grip that will not slip
- Straight, half-round, long and slim knurled jaws, specially profiled
- Side cutting edge for wire cutting
- Space for up to 3 pliers and 5 screwdrivers
- Rolls shut
- Closes with hook and loop fastener
IPHS1 Phillips Screwdriver
IPHS2 Phillips Screwdriver
ISLS3 Slotted Screwdriver
ISLS5 Slotted Screwdriver
ISLS8 Slotted Screwdriver
INCP8 Insulated Lineman's Combination Pliers
INDC8 Insulated High Leverage Diagonal Cutter
INLP8 Insulated Long Nose Pliers
RUP8 Roll-up Tool Pouch
