Fowler 52-520-109-0 .001" AGD Indicator - Black

Fowler® Chrome Flex Mag And Indi-X Blue Electronic Indicator Set Fowler® Chrome Flex Mag And Indi-X Blue Electronic Indicator Sets include an Indi-X Blue Electronic Indicator, a Flex Arm Mag Base and a Magnetic Indicator Back. The Indi-X Blue Electronic Indicator has a 2-1/4" dial face, a 1"/25mm travel, tolerance indicators, absolute/incremental reading, floating zero, an auto Off feature, a carbide tipped point, lug back and 3/8" stem mountings. The Flex Arm Mag Base has a corrosion resistant chrome plated flex arm, an 85 lb. pull magnet and a V-base for mounting on rounded surfaces. ...

Our digital Indicator offer easy reading, super precision, with both Inch and Metric Measurements. Features: Extra large digits display Analog bar display with adjustable range and tolerance indicators Fast visual indication whether out of pre-set tolerance or not Fast to read max./min. measurement Stem diameter 3/8" TIR function Zero-set for comparison measurements (Floating zero) Inch/Metric Conversion Range: 0 - 1" / 0 - 25.4mm Accuracy: +/- 0.0005" Repeatability: 0.0005" Resolution: 0.0005" / 0.01mm Super large LCD screen Optional lug back plate included Instructions included

The Starrett® Shaft Alignment Clamp is designed for fast, precise alignment of motors, pumps, compressors, etc. This system is capable of addressing radial and angular misalignment problems and can be set up within minutes. Features: Lightweight clamp design made of black anodized aluminum Rigid 3/8" diameter stainless steel indicator posts provided in three lengths (5", 7-7/16", and 9") Extension plate allows for added radial clearance Heavy-duty roller chain can accommodate up to a 7-1/2" diameter shaft Set comes with two Starrett® 196B5 Indicators Excess roller chain can be secured to ...

Fowler® 52-585-155-0 X-Proof Water Resistant Indicator Set Magnetic Base: Fine adjustment Base dimensions: 2" x 2-11/32" x 1-13/16" Also mounts test indicators with 1/4" post 85 lb. pull On-Off lever release magnet V-base for placing on round surfaces X-Proof Indicator: Travel: 1" Reading: .001" Continuous reading: 0-100 Tolerance markers AGD Group 2, 2-1/4" dia. Lugback and carbide point Robust, shockproof design Rubber bellows on stem O-ring seal on safety cap O-ring protection for bezel and rotating dial Sealed back plate

Features: Length: 6 7/8" Shank dia.: 3/8" x 7/8" long Feeler dia.: 1/8" Measuring range: 0.25" of axis Dial reading: 0 - 50 Graduation: 0.0005" Includes 6 Feelers: 4", 8", 12" Straight 4", 8", 12" Curved Capacity: 5/32" - 4 1/4" internal 0 - 4 1/4" external Locating accuracy is 0.0005" of center Operates at any angle from horizontal to vertical without any change, and from internal to external by simply changing the feeler Supplied in a fitted wood case This set includes: Indicator body, restraining rod (prevents rotation), spring-loaded center point feeler, three straight feelers (for ...
