Technical Data:
- Capacity Under Guides:
- 12" Round @ 90°
- 12" x 10" Rectangle @ 90°
- 9" Round @ 45°
- 9" Square @ 45°
- 6" Round @ 60°
- 6" Square @ 60°
- Blade Size: 1" Width x 11' 8" Length .035 thick (bi-metal)
- Swivel: Swivels 60° both directions
- Blade Guards: Pulleys and blade
- Blade Speeds: 70/140/270 sfpm
- Table Height: 30" from floor
- Feed Systems: Hydraulic cylinder for controlled feeds
- Wheels: Cast Iron Wheels
- Dimensions: 26" Width x 63" Height x 73" Length
- Blade cleaning brush
- Adjustable cast iron guide arms
- Automatic shutoff (safety magnetic starter)
- Quick action vise (can be moved to either side)
- Side Splash Panels
- Coolant Pump: 3.5 gpm
- Coolant Reservoir: 8 gallon with adjustable needle valve flow control
